Point Source Loudspeakers

15” Passive Subwoofer with Bass Reflex

VX15B

  • 15” dedicated subwoofer for the PENTON PRO VX Series
  • Deep, controlled bass down to 42 Hz
  • 132 dB SPL @ 1 m with ultra-low distortion (<0.5%)
  • Direct-radiating bass reflex design, omnidirectional coverage
  • 800–1000 W @ 8 Ω recommended amplifier power
  • Rugged plywood enclosure with impact & water-resistant finish
  • 15” Passive Subwoofer with Bass Reflex (0)
  • 15” Passive Subwoofer with Bass Reflex (1)

The VX15B is the dedicated subwoofer in the PENTON PRO series, designed to deliver deep, controlled bass extension in a compact and rugged enclosure. Ideal for venues demanding impactful low-frequency reinforcement, it perfectly complements the VX Series full-range loudspeakers. Built around a long-throw 15” high-sensitivity low-frequency driver, the VX15B uses a direct-radiating bass reflex design with an omnidirectional dispersion pattern, delivering tight, punchy bass down to 42 Hz and output levels reaching 132 dB SPL @ 1m.

With ultra-low harmonic distortion (<0.5% at rated power) and a recommended amplifier power of 800–1000 W @ 8 Ohms, the VX15B is engineered to perform reliably in demanding live or installed sound environments. Its enclosure is built from multi-layer plywood, coated with impact- and water-resistant paint, and protected by a metal grille with acoustically transparent foam. M8 mounting points and a 35 mm pole socket on the top panel allow straightforward mobile setups with VX full-range loudspeakers.

Perfect for clubs, concert halls, theatres, and sports facilities, the VX15B adds power, depth, and versatility to any professional sound system.

  • Dedicated passive subwoofer for the Penton Pro VX Series
  • Installation high performance
  • Direct-radiating bass reflex design – for tight and punchy low frequencies
  • Long-throw high-sensitivity low-frequency driver – for powerful bass response
  • Frequency range down to 42 Hz – for extended low-end performance
  • Robust enclosure – multi-layer plywood with impact- and water-resistant paint
  • Flexible mounting options – M8 inserts and 35 mm pole mount socket
  • Components: 15”
  • Coverage: Omnidirectional
  • Frequency range (-3 dB), Hz: 48 – 200
  • Frequency range (-6 dB), Hz: 42 – 200
  • Maximum sound pressure 1 m (SPL) @ 1 m, dB: 132
  • Harmonic distortion, rated power: <0.5%
  • Harmonic distortion, maximum power: <1.4%
  • Directional pattern: Circular
  • Impedance, Ohm: 8
  • Rated power, Watts: 800
  • Peak power (10ms), Watts: 1000
  • Connectors: 1 x NL4, 1 x Phoenix 4pin
  • Dimensions WxHxD, mm: 500 x 568 x 540
  • Weight, kg: 34.2
  • Colour: Black
  • Clubs
  • Concert halls
  • Theaters
  • Conference rooms
  • Fitness spaces
  • ...

Type
Filename
Download
Datasheet
Type: [PDF]
Filename: VX15B_Datasheet
Download:

Type
Filename
Download
Datasheet
Type: [PDF]
Filename: VX15B_Fiche produit
Download:

Type
Filename
Download
Datasheet
Type: [PDF]
Filename: VX15B_Datenblatt
Download:
